Send InquiryLife Raft Davit
MOQ : 01 Unit
Life Raft Davit Specification
- Capacity
- 10 to 25 persons (suitable for 1-2 life rafts, depending on model)
- Application Areas
- Cargo ships, tankers, offshore platforms, marine vessels
- Equipment Type
- Life Raft Launching Davit
- Operating Temperature
- -20C to +55C
- Working Pressure
- 16 MPa (Hydraulic system)
- IP Rating
- IP56 for control panel and motor unit
- Flow Rate
- As per hydraulic winch specification (approx. 4-8 L/min)
- Usage & Applications
- Lifting and launching life rafts in emergency situations on ships and offshore platforms
- Product Type
- Marine Safety Equipment
- Type
- Gravity Type Davit
- Material
- High strength marine steel, galvanized or stainless steel finish
- Automatic Grade
- Semi-Automatic / Manual Operation
- Control System
- Manual and hydraulic control
- Drive Type
- Hydraulic drive with manual backup
- Weight (kg)
- 900 - 1800 kg (varies as per capacity/model)
- Dimension (L*W*H)
- 3200 mm x 1600 mm x 2600 mm (approximate, varies with model)
- Feature
- Corrosion resistant, compact design, strong lifting capability
- Warranty
- 1
- Size
- Customized as per vessel specification
- Voltage
- 380V / 415V AC, 3 Phase
- Surface Finishing
- Marine grade epoxy paint, hot dip galvanized
- Power Source
- Electric/Hydraulic
- Features
- Weatherproof construction, easy installation, compliance with SOLAS & IMO
- Mounting Type
- Deck mounted
- Launching Speed
- 18 m/min (nominal)
- Storage Condition
- Covering/protective housing recommended when not in use
- Wire Rope Diameter
- 16 mm (standards-compliant steel wire rope)
- Safety Device
- Overload protection, emergency manual release
- Slewing Angle
- 90
- Ambient Humidity
- 95% RH
- Operation Mode
- Manual and electric
- Maintenance
- Low maintenance, with accessible inspection points
- Max Working Load
- 25 kN
Life Raft Davit Trade Information
- Minimum Order Quantity
- 01 Unit
- FOB Port
- Mumbai
- Supply Ability
- Unit
- Delivery Time
- 4 Week
- Main Export Market(s)
- Australia, North America, Eastern Europe, Middle East, South America, Western Europe, Africa, Central America, Asia
- Main Domestic Market
- All India
- Certifications
- ISO 9001:2008 Certified Company
Life Raft Davit About
Jump on this highlighted, first-rate Life Raft Davit engineered for transcendent performance during emergency liferaft launching. With a nominal launching speed of 18 m/min and a maximum working load of 25 kN, this sensational equipment features standards-compliant steel wire rope (16 mm diameter) and a robust slewing angle of 90. The corrosion-resistant, compact design ensures durability and low maintenance, while accessible inspection points provide convenience. Benefit from its sensational safety features - overload protection and emergency manual release. Avail yourself of our attractive discount offers. Ideal for marine vessels, tankers, and offshore platforms, available in customized sizes and finishes for export worldwide.
Exceptional Features & Versatile Use
This Gravity Type Life Raft Launching Davit comes with highlighted special features such as corrosion resistance, compact construction, and strong lifting capability suitable for rapid response. Its dual operation modes-manual and electric-ensure flexibility in critical situations. Designed for both ships and offshore platforms, it accommodates 10-25 persons, making it ideal for installation on cargo vessels, tankers, and marine crafts. Its weatherproof construction and SOLAS & IMO compliance further reinforce safety and reliability.
Export Markets, Payment & Certification Advantages
Express shipping and reliable freight options are available for global handover, ensuring timely delivery to key export markets including Asia, Europe, the Middle East, and Africa. Multiple payment terms, including LC, TT, and advance, are supported for streamlined transactions. Each davit comes certified to meet SOLAS and IMO regulations, along with IP56 ratings for control panels and motor units, assuring premium quality and regulatory compliance for marine safety worldwide.
Exceptional Features & Versatile Use
This Gravity Type Life Raft Launching Davit comes with highlighted special features such as corrosion resistance, compact construction, and strong lifting capability suitable for rapid response. Its dual operation modes-manual and electric-ensure flexibility in critical situations. Designed for both ships and offshore platforms, it accommodates 10-25 persons, making it ideal for installation on cargo vessels, tankers, and marine crafts. Its weatherproof construction and SOLAS & IMO compliance further reinforce safety and reliability.
Export Markets, Payment & Certification Advantages
Express shipping and reliable freight options are available for global handover, ensuring timely delivery to key export markets including Asia, Europe, the Middle East, and Africa. Multiple payment terms, including LC, TT, and advance, are supported for streamlined transactions. Each davit comes certified to meet SOLAS and IMO regulations, along with IP56 ratings for control panels and motor units, assuring premium quality and regulatory compliance for marine safety worldwide.
FAQ's of Life Raft Davit:
Q: How does the Life Raft Davit ensure safety during operations?
A: The Life Raft Davit is equipped with safety devices like overload protection and emergency manual release to guarantee safe lifting and launching, even in challenging conditions.Q: What maintenance is required for this Life Raft Davit?
A: This davit is designed for low maintenance, featuring accessible inspection points and corrosion-resistant materials to ensure longevity and reliability with minimal upkeep.Q: Where can the Life Raft Davit be used?
A: It is suitable for use on cargo ships, tankers, offshore platforms, and marine vessels-making it versatile for both new installations and retrofits across maritime sectors.Q: When is it recommended to cover or store the davit?
A: It is recommended to use covering or protective housing when the davit is not in active use to extend its operational life and resist weather elements.Q: What is the process for installation and operation of this davit?
A: The davit is designed for easy deck-mounted installation, with both manual and electric operation modes. Hydraulic and manual controls allow smooth handling during emergency launches.Q: What certifications does the Life Raft Davit hold?
A: The davit complies with SOLAS and IMO standards and is supplied with IP56 rating certification for electrical components, ensuring reliability and international compliance.
